Palm fruit oil press

Single Screw Palm Oil Press is a kind of oil extraction equipment used to extract palm oil from palm fruits, with a capacity between 0.5TPH-3TPH. This is a palm oil press machine designed and manufactured by Siwei Group according to the characteristics of palm fruits. The gap between the worm and the distance between the worm and the barrel are carefully designed, while the oil press is made of wear-resistant alloy steel, which ensures the smooth production process of palm oil and also ensures that the palm kernel is well preserved for deep processing. Here’s a look at the details of the single screw palm oil press:

 Single screw palm oil press operating procedure:

• Before producing palm oil with single screw palm oil press machine, the palm fruit bunches should be processed first. Separate the palm fruits from the palm fruit bunches first, and then sterilize them, so that it can be easier to extract palm oil from palm fruits with high pressing efficiency.
• When producing palm oil, the single screw palm oil press is started first, and the palm fruits are conveyed into the feeding hole of the press for pressing. At the beginning of pressing, it is necessary to manually adjust the pressure of the press chamber according to the situation of cake output, so that the pressing effect can reach a good result. After pressing, you can get the crude palm oil.
• Double screw palm oil press machine is suitable for oil pressing equipment in large and medium-sized palm oil production line, which can extract palm oil from palm fruits with capacity of 5TPH,10TPH and 15TPH respectively.

Main structure of double screw oil press

The main structure includes mainframe, press cage, press screw, hydraulic control system, motor, gear box, reducer and other parts. Among them, the hydraulic control system is the main  and highlight of the double screw palm oil press, which can adjust the pressure in the press cage according to the situation of palm pressing, so that the palm oil pressing process goes smoothly.

Double screw oil press working principle

Double screw palm oil press machine produces palm oil by utilising the squeezing of two oppositely running press screws in the press cage. The hydraulic control system in the press can also regulate the pressure inside the cage so that the pressing process is not affected. After pressing, not only crude palm oil but also intact palm kernels can be obtained. Customer can sell kernels to palm kernel oil processing plant for extra profit. Or they can choose to do deep processing to produce palm kernel oil by themselves.
